Name: Dual source heat pump
Brand: Wedy
Price: 2000 USD

Add to Cart

	Double source heat pump hot water unit
Model No			MG-100SYXRS	MG-200SYXRS	MG-250SYXRS
		Size (WDH)	15808001600	17501120900	17501120900
		Compressor	Copeland
		Gas	R407C
		Voltage	380V/50Hz
		Thermostatic expansion valve	Danfoss
		Controler	Mango Motorola chip
		Unit access power line	310mm2+26mm2	316mm2+210mm2	316mm2+210mm2
	Water source heat pump	Heating capacity (kW)	41.1	78.5	99
		Input power(kW)	8.48	16.3	20.5
		Current(A)	16.8	34.5	41.4
		COP	4.85	4.82	4.83
		Delivery Hot water volume(L/H)	883	1650	2128
		Noise (dB(A))	≤56	≤56	≤56
	Air source heat pump	Reted heating output(kW)	38	73.5	95
		Heating input power (kW)	9	18	22.8
		Current(A)	17.6	36.1	44.8
		COP	4.22	4.08	4.17
		Delivery Hot water volume(L/H)	817	1580	2042
		Noise (dB(A))	≤66	≤66	≤66
	Heat source side water flow (m3/H)		11.5	21.2	27.2
	Use side water flow (m3/H)		10	20	25
	Rated Output Water Temp(℃)		55	55	55
	Max Output Water Temp(℃)		60	60	60
	N.W/G.W(kg)		310/330	502/552	592/652
Water source model test condition:Heat source side inlet & outlet water temp 15℃/10℃
Hot water initial temp 15℃,Hot water end of temp 55℃；

Air source model test condition:Dry bulb temperature 20℃, wet bulb temperature 15℃,
Hot water initial temp 15℃,Hot water end of temp 55℃；
